EURMilesight WS513 - Wall Socket (built-in) - Variant: Type E
Milesight WS513 - Wall Socket (built-in) - Variant: Type E
Smart built-in socket with LoRaWAN support for remote control and energy consumption monitoring. More
Manufacturer: Milesight
Product code: 99.25.1857.5163
Free shipping within the Czech Republic on purchases over 125 USD.
98,90 USD
excl. VAT (119,67 USD incl. VAT)
Smart built-in socket with LoRaWAN support for remote control and energy consumption monitoring. More
Manufacturer: Milesight
Product code: 99.25.1857.5163
Milesight WS513 is a smart built-in socket with LoRaWAN support, enabling remote control and energy consumption monitoring. It supports local control via button, mobile app operation, scheduling, and includes advanced features like overload protection and button lock. The device is compatible with Milesight IoT Cloud and standard LoRaWAN gateways.
Specifications
- Socket Type: Type E (FR) or Type F (EU)
- Input Voltage: 100–250 V AC, 50/60 Hz
- Maximum Current: 16 A
- Measured Parameters: voltage, current, power factor, active power, energy consumption
- Dimensions: 86.3 × 86.3 × 43.3 mm
Parameters
| Model | WS513-868M-16A-W11-FR |
|---|---|
| Socket Type | Type E (FR) or Type F (EU) |
| Input Voltage | 100–250 V AC, 50/60 Hz |
| Maximum Current | 16 A |
| Measured Parameters | Voltage (V), current (mA), power factor (%), active power (W), energy consumption (kWh) |
| Measurement Accuracy | Typical ±3%, maximum ±5% (±1% optional) |
| Communication Technology | LoRaWAN®, Milesight D2D |
| Frequency Bands | IN865 / RU864 / EU868 / US915 / AU915 / KR920 / AS923-1, AS923-2, AS923-3, AS923-4 |
| Transmit Power | 16 dBm (868 MHz) |
| Receiver Sensitivity | -137 dBm |
| Operating Modes | OTAA / ABP, Class C |
| Configuration | NFC or downlink |
| Power Control | Local button or remote control |
| Advanced Features | Delayed switching, button lock, overload protection, multicast, Milesight D2D agent |
| LED Indicator | 1× status/power LED |
| Material and Color | Polycarbonate (UL94 V0), white |
| Dimensions | 86.3 × 86.3 × 43.3 mm (Type E) |
| Weight | 98.8 g |
| Operating Temperature | -20 °C to +60 °C |
| Relative Humidity | 0% to 95% (non-condensing) |
| Ingress Protection | IP20 |
| Certifications | CE, RoHS, WEEE |
