EURMilesight UC511 - LoRaWAN Solenoid Valve Controller
Milesight UC511 - LoRaWAN Solenoid Valve Controller
Free shipping within the Czech Republic on purchases over 120 EUR.
The Milesight UC511-868M is a solar-powered LoRaWAN® controller for remote irrigation valve control. It drives two 12 VDC two-wire latching solenoids to open and close valves locally over NFC or remotely via LoRaWAN® and the Milesight IoT Cloud, and its two pulse inputs monitor up to two water meters for flow-based control. It supports time- and flow-based scheduling with local rules for offline operation and Milesight D2D.
The unit runs on two rechargeable Li-ion cells kept charged by an embedded 6 V / 1.7 W solar panel, giving multi-year autonomy in Class A. Housed in an IP68 outdoor enclosure with M12 connectors, it mounts on a wall or pole — for agricultural, landscape and garden irrigation.
Before deployment
- Setup: via the Milesight ToolBox app (NFC) or over USB-C.
- Power: solar panel and rechargeable battery (2× 2550 mAh), or DC 5–24 V.
- Inputs & outputs: 2× outputs for latching 12 V DC solenoid valves + a pulse input for a water meter.
- Data: over LoRaWAN — needs a LoRaWAN gateway to send data (sold separately); remote monitoring via the Milesight platform is free for up to 10 devices.
Parameters
| Wireless Protocol | LoRaWAN®, Class A/B/C (OTAA/ABP), Milesight D2D support |
| Frequency | EU868, max. 16 dBm |
| Function | Remote irrigation valve control; time/flow scheduling; local rules for offline control |
| Outputs / Control | 2 × solenoid outputs (2-wire 12 VDC latching, M12); 2 × pulse inputs (water meters) |
| Power | 2 × 2550 mAh rechargeable Li-ion + solar panel 6 V / 1.7 W; external DC 5–24 V (M12) |
| Configuration | NFC via Mobile App, Downlink |
| Enclosure | IP68 outdoor enclosure, M12 connectors |
| Dimensions | 116 × 116 × 45.5 mm |
| Weight | 425 g (with batteries) |
| Mounting | Wall or pole |
| Certifications | CE, FCC, RoHS |
