EURMilesight AT101 - Outdoor Asset Tracker
Milesight AT101 - Outdoor Asset Tracker
LoRaWAN® outdoor asset tracker with GNSS + Wi-Fi positioning, tilt detection and temperature. IP67 & IK09, over 15-year battery life, geofencing. More
Manufacturer: Milesight
Product code: 99.26.3475.2606
Free shipping within the Czech Republic on purchases over 120 EUR.
139 EUR
excl. VAT (168,19 EUR incl. VAT)
Price includes a WEEE recycling fee for the Czech Republic.
LoRaWAN® outdoor asset tracker with GNSS + Wi-Fi positioning, tilt detection and temperature. IP67 & IK09, over 15-year battery life, geofencing. More
Price includes a WEEE recycling fee for the Czech Republic.
Manufacturer: Milesight
Product code: 99.26.3475.2606
The Milesight AT101-868M is a rugged outdoor LoRaWAN® asset tracker combining GNSS and Wi-Fi positioning for accurate location outdoors and indoors. It adds a 3-axis accelerometer for tilt/movement detection and an NTC temperature sensor, in an IP67 / IK09 enclosure.
Four replaceable 2700 mAh Li-SOCl₂ batteries give over 15 years of operation with twice-daily reports. It supports geofencing, tilt and tamper alarms, and is configured via NFC or Bluetooth — ideal for fleet, construction, warehouse and livestock tracking.
Before you install
- Setup: via the Milesight ToolBox app (NFC).
- Power: 4× lithium batteries (ER14505) included, 15+ year life.
- Data: over LoRaWAN — needs a LoRaWAN gateway to send data (sold separately); remote monitoring via the Milesight platform is free for up to 10 devices.
Parameters
| Wireless Protocol | LoRaWAN®, Class A (OTAA/ABP) |
| Frequency | EU868, max. 16 dBm |
| Positioning | GNSS (CEP 5 m) + Wi-Fi scanning; Bluetooth 5.3 for configuration |
| Temperature | Onboard NTC, –40 °C to +125 °C; 3-axis tilt/motion detection |
| Configuration | NFC, Bluetooth 5.3, Downlink |
| Battery | 4 × 2700 mAh Li-SOCl₂ (ER14505), over 15 years |
| Enclosure | PC, IP67, impact protection IK09 |
| Operating Temperature | –30 °C to +70 °C |
| Dimensions | 110 × 70 × 30 mm |
| Mounting | Wall screw, tape, or cable tie |
| Certifications | CE, FCC, RoHS |
Documentation
Safety information
- Read the manufacturer's user guide supplied with the product before installation and keep it.
- Use the product only for its intended use and within the operating conditions stated by the manufacturer. Do not use a visibly damaged product.
- Replace the batteries only with the type given in the documentation and insert them with the correct polarity (+ and −).
- Never recharge primary (non-rechargeable) cells. Do not short-circuit, open, crush or heat batteries and do not throw them into fire.
- Keep batteries out of the reach of children.
- A damaged or leaking battery can overheat or catch fire: take it out of service and do not touch leaking electrolyte.
| Manufacturing company | XIAMEN MILESIGHT IOT CO.,LTD. |
|---|---|
| Address | 401, Building No.37, Xixishanwei Road, Software Park Phase III, Torch Development Zone for High Technology Industries, Xiamen, China |
| [email protected] | |
| Manufacturer's representative in the EU | HARDWARIO a.s. |
| Address of representative in the EU | U Jezu 525/4, 460 01 Liberec, Czech Republic |
| EU representative email | [email protected] |
