Milesight TS302 - Dual-Channel Temperature Sensor with Display
Free shipping within the Czech Republic on purchases over 120 EUR.
The Milesight TS302-868M is a dual-channel LoRaWAN® temperature sensor with two 5-pin M12 connectors, allowing two detachable probes (or one probe plus a magnet switch) to be monitored from a single unit. Optional PT100, DS18B20 and temperature/humidity probes cover ranges from –200 °C to +500 °C. EN12830 certification and HACCP/21 CFR Part 11 support make it ideal for cold-chain, food and pharmaceutical storage.
A built-in low-power LCD shows readings on the device. It is powered by two replaceable 4000 mAh Li-SOCl₂ batteries or USB-C, logs locally with export/retransmission, supports Milesight D2D, and is configured via NFC. In an IP65 enclosure. Probes are ordered separately.
Before you install
- Setup: via the Milesight ToolBox app (NFC) or over USB-C.
- Power: 2× lithium batteries (ER18505) or USB-C.
- Data: over LoRaWAN — needs a LoRaWAN gateway to send data (sold separately); remote monitoring via the Milesight platform is free for up to 10 devices. Also supports Milesight D2D for direct control without a gateway.
Parameters
| Wireless Protocol | LoRaWAN®, Class A (OTAA/ABP), Milesight D2D support |
| Frequency | EU868, max. 16 dBm |
| Probe / Sensor | 2 × M12 connector; optional PT100 / DS18B20 / TH probes (sold separately), –200 °C to +500 °C |
| Temperature | Depends on probe; accuracy from ±0.4 °C, resolution 0.1 °C; EN12830 compliant |
| Display | Built-in low-power LCD |
| Configuration | NFC via Mobile App, USB-C, Downlink |
| Battery | 2 × 4000 mAh Li-SOCl₂ (ER18505) or USB-C |
| Enclosure | IP65 |
| Dimensions | 109.35 × 75 × 29 mm |
| Weight | 185 g |
| Mounting | Wall screw, magnetic (optional) |
| Certifications | CE, FCC, EN12830, RoHS |
