Milesight UC300 LoRaWAN IoT Controller

Milesight UC300 LoRaWAN IoT Controller


Industrial LoRaWAN® controller with RS485/RS232, digital I/O, relay outputs, analog (4–20 mA / 0–10 V) and PT100 inputs. Edge logic, DC 5–24 V, DIN-rail metal enclosure. More
Manufacturer: Milesight Product code: 99.26.3650.8190

Free shipping from 125 EUR in the Czech Republic, 150 EUR to Slovakia and 250 EUR to all other countries we ship to (order value incl. VAT). All rates: Shipping and payment.

EU companies outside the Czech Republic with a valid VAT ID buy without VAT (reverse charge).

139 EUR incl. VAT

Price includes a WEEE recycling fee for the Czech Republic.

Usually ships in 7 days
Industrial LoRaWAN® controller with RS485/RS232, digital I/O, relay outputs, analog (4–20 mA / 0–10 V) and PT100 inputs. Edge logic, DC 5–24 V, DIN-rail metal enclosure. More

Price includes a WEEE recycling fee for the Czech Republic.

Manufacturer: Milesight Product code: 99.26.3650.8190

The Milesight UC300-868M is an industrial IoT controller with a broad mix of wired interfaces for monitoring and controlling field equipment: RS485 and RS232 serial ports, four digital inputs (with pulse counting), two relay outputs, four analog inputs (2 × 4–20 mA and 2 × 0–10 V) and two PT100 temperature inputs, reporting over LoRaWAN® Class C.

It supports on-device logic such as thresholds and event triggers for local automation independent of the network, plus Milesight D2D. Powered from a 5–24 VDC supply in a metal IP30 enclosure, it mounts on DIN rail, wall or desktop. Typical uses: industrial automation, Modbus gateway and remote equipment monitoring.

Before deployment

  • Setup: PC software (ToolBox) over USB-C.
  • Power: DC 5–24 V, adapter included.
  • Inputs & outputs: 4× digital inputs, 2× relay outputs, 4× analog inputs (0–10 V / 4–20 mA), 2× PT100, RS232 and RS485 (Modbus).
  • Data: over LoRaWAN, needs a LoRaWAN gateway (sold separately); also supports Milesight D2D.

Parameters

Wireless Protocol LoRaWAN®, Class C (OTAA/ABP), Milesight D2D support
Frequency EU868, max. 16 dBm
Function Industrial multi-interface data acquisition & control; edge logic (thresholds, triggers)
Interfaces / I/O 1 × RS485, 1 × RS232, 4 × DI (pulse), 2 × DO relay (3 A), 2 × AI 4–20 mA, 2 × AI 0–10 V, 2 × PT100
Power DC 5–24 V
Configuration USB-C (ToolBox PC software), Downlink
Enclosure Metal, IP30
Dimensions 93 × 70 × 22 mm
Weight 142 g
Mounting DIN rail, wall or desktop
Certifications CE, FCC

Documentation

Safety information

  • Read the manufacturer's user guide supplied with the product before installation and keep it.
  • Use the product only for its intended use and within the operating conditions stated by the manufacturer. Do not use a visibly damaged product.
  • Power the device only from the power supply or PoE source stated by the manufacturer and keep it adequately ventilated.
Manufacturing company XIAMEN MILESIGHT IOT CO.,LTD.
Address 401, Building No.37, Xixishanwei Road, Software Park Phase III, Torch Development Zone for High Technology Industries, Xiamen, China
Email [email protected]
Responsible person in the EU HARDWARIO a.s.
Address of the responsible person in the EU U Jezu 525/4, 460 01 Liberec, Czech Republic
E-mail of the responsible person in the EU [email protected]
