EURMilesight UG65 - Gateway With PoE
Milesight UG65 - Gateway With PoE
High-performance 8-channel LoRaWAN gateway with Wi-Fi, MQTT support, and PoE power supply. More
Manufacturer: Milesight
Product code: 99.25.1294.4302
Free shipping within the Czech Republic.
409 EUR
excl. VAT (494,89 EUR incl. VAT)
High-performance 8-channel LoRaWAN gateway with Wi-Fi, MQTT support, and PoE power supply. More
Manufacturer: Milesight
Product code: 99.25.1294.4302
The LoRaWAN gateway with PoE support offers reliable IoT device connectivity and easy integration into existing networks. Thanks to the 8-channel SX1302 receiver and the possibility of a PoE power supply, it is suitable even for demanding industrial or enterprise deployments.
Ethernet and Wi-Fi connections enable flexible installation in various scenarios. The integrated MQTT protocol and support for platforms such as The Things Network or ChirpStack ensure easy integration with existing infrastructure.
Before deployment
- Power: a DC adapter (9–24 V) is included, or PoE 802.3af (injector not included).
- Connectivity: gigabit Ethernet and Wi-Fi (optional 4G LTE).
- Management: a built-in LoRaWAN network server (~2000 nodes), runs standalone; set up via the web interface, remote management via the Milesight platform.
Parameters
| Number of Channels | 8 |
|---|---|
| LoRa Chip | Semtech SX1302 |
| Frequency Bands | 433/470/868/915/920/923/865/864 MHz |
| Output Power | Up to 27 dBm |
| Receiver Sensitivity | Up to -140 dBm |
| Processor | Quad-core ARM Cortex-A53, DDR4 RAM 512 MB |
| Power Supply | DC 9–24 V or PoE (IEEE802.3 af), 36~57 V |
| Interfaces | Ethernet, SD, USB, DC, ANT |
| Wi-Fi | 2.4 GHz (802.11b/g/n) |
| Protocols | LoRaWAN 1.0.3, MQTT |
| Operating System | OpenWRT with a web interface |
| Platform Support | ChirpStack, TTN, Tencent Cloud IoT, LoRa Web Servers |
| Dimensions | 180 × 110 × 56.5 mm |
| Weight | 548 g |
