EURMilesight WS203 - Motion & Temperature/Humidity Sensor
Milesight WS203 - Motion & Temperature/Humidity Sensor
LoRaWAN® 3-in-1 sensor combining PIR motion (up to 6 m) with temperature and humidity. Interchangeable field-of-view covers, up to 10-year battery life, Milesight D2D. More
Manufacturer: Milesight
Product code: 99.26.3635.2701
Free shipping within the Czech Republic on purchases over 120 EUR.
53,90 EUR
excl. VAT (65,22 EUR incl. VAT)
LoRaWAN® 3-in-1 sensor combining PIR motion (up to 6 m) with temperature and humidity. Interchangeable field-of-view covers, up to 10-year battery life, Milesight D2D. More
Manufacturer: Milesight
Product code: 99.26.3635.2701
The Milesight WS203-868M combines a passive-infrared motion detector (up to 6 m) with built-in temperature and humidity sensing. Interchangeable Fresnel-lens covers adjust the detection field between a wide 120° × 100° pattern and narrower angles to suit the installation.
It measures –20 °C to +60 °C (±0.2 °C) and 0–100 % RH (±2 %), runs up to 10 years on a 4000 mAh Li-SOCl₂ battery, stores records locally with retransmission, supports Milesight D2D and is configured via NFC. UL94 V0 flame-retardant IP30 enclosure.
Before you install
- Setup: via the Milesight ToolBox app (NFC).
- Power: a lithium battery (ER18505) included, up to ~10-year life.
- Data: over LoRaWAN — needs a LoRaWAN gateway to send data (sold separately); remote monitoring via the Milesight platform is free for up to 10 devices. Also supports Milesight D2D for direct control without a gateway.
Parameters
| Wireless Protocol | LoRaWAN®, Class A (OTAA/ABP), Milesight D2D support |
| Frequency | EU868, max. 16 dBm |
| Detection | PIR motion up to 6 m; FoV 120° H × 100° V (adjustable via covers) |
| Temperature | –20 °C to +60 °C, accuracy ±0.2 °C (0–60 °C), resolution 0.1 °C |
| Humidity | 0–100 % RH, accuracy ±2 % (@25 °C), resolution 0.5 % RH |
| Configuration | NFC via Mobile App, Downlink |
| Battery | 4000 mAh Li-SOCl₂ (ER18505), up to 10 years |
| Enclosure | PC+ABS (UL94 V0), IP30 |
| Dimensions | 73 × 73 × 26 mm |
| Weight | 89.6 g |
| Mounting | 3M tape or wall screws |
| Certifications | CE, FCC, RoHS |
