EURMilesight WS502 - Smart Wall Switch (2-Gang)
Milesight WS502 - Smart Wall Switch (2-Gang)
LoRaWAN® 2-gang smart wall switch controlling two independent circuits, with energy metering, overcurrent protection and D2D. Fits an 86 mm wall box; up to 1000 W per gang / 10 A total. More
Manufacturer: Milesight
Product code: 99.26.3654.4319
Free shipping within the Czech Republic on purchases over 120 EUR.
61,90 EUR
excl. VAT (74,90 EUR incl. VAT)
LoRaWAN® 2-gang smart wall switch controlling two independent circuits, with energy metering, overcurrent protection and D2D. Fits an 86 mm wall box; up to 1000 W per gang / 10 A total. More
Manufacturer: Milesight
Product code: 99.26.3654.4319
The Milesight WS502-868M is a two-gang LoRaWAN® wall switch that independently controls two lighting or appliance circuits via high-reliability relays, replacing a conventional 2-gang switch. It provides voltage, current, power-factor, active-power and energy metering, along with overcurrent protection, delay switching, switch lock and multicast.
It runs LoRaWAN® Class C with Milesight D2D for gateway-less control. Mains-powered (100–250 VAC) with a 3-wire connection (neutral required), each gang switches up to 1000 W (10 A resistive) with a 10 A combined limit; it fits a standard 86 mm wall box and is configured via NFC.
Before you install
- Setup: via the Milesight ToolBox app (NFC).
- Power: hard-wired to mains (100–250 V), requires a neutral wire — wired by an electrician.
- Control: switches two independent circuits; remotely via a LoRaWAN gateway (sold separately) or directly via Milesight D2D without a gateway; energy metering, indoor only.
Parameters
| Wireless Protocol | LoRaWAN®, Class C (OTAA/ABP), Milesight D2D support |
| Frequency | EU868, max. 16 dBm |
| Function | 2-gang independent control of lights/appliances; delay switch, switch lock, multicast |
| Electrical | 100–250 VAC, 50–60 Hz; 2 gangs; 10 A resistive / 5 A inductive per gang, 10 A total; max 1000 W/gang; 3-wire, neutral required |
| Energy Metering | Voltage, current, power factor, active power, energy (kWh); accuracy ±3 % |
| Power | Mains (100–250 VAC) |
| Configuration | NFC via Mobile App, Downlink |
| Enclosure | PC (UL94 V0), IP20 |
| Dimensions | 86 × 86 × 40 mm |
| Weight | 103 g |
| Mounting | Standard 86 mm square wall box |
| Certifications | CE, FCC, RoHS |
