EURMilesight WT303 - Smart Fan Coil Thermostat
Milesight WT303 - Smart Fan Coil Thermostat
Free shipping within the Czech Republic on purchases over 120 EUR.
Price includes a WEEE recycling fee for the Czech Republic.
Price includes a WEEE recycling fee for the Czech Republic.
The Milesight WT303-868M is a room thermostat for 2-pipe and 4-pipe fan-coil units with 3-speed fans. It drives switch-type (on/off) motorized valves and the fan with Heat, Cool and Ventilation modes, supports up to 8 plans of 16 schedules each, and offers open-window detection, freeze protection, fan delay and child lock. A dry-contact input allows keycard/magnet switching.
A 2.7" E-Ink screen shows temperature, humidity and status from the onboard CMOSens sensor; an external NTC input is also provided. It is mains-powered (100–240 VAC), communicates over LoRaWAN® Class C with Milesight D2D, and is BACnet-compatible via Milesight gateways. Configuration is via NFC.
Before you install
- Setup: via the Milesight ToolBox app (NFC).
- Power: mains 100–240 V — wired by an electrician.
- Control: controls fan-coil units (2/4-pipe, 3-speed fan and valves); remotely via a LoRaWAN gateway (sold separately) or directly via Milesight D2D.
Parameters
| Wireless Protocol | LoRaWAN®, Class C (OTAA/ABP), Milesight D2D support |
| Frequency | EU868, max. 16 dBm |
| Function | 2-pipe/4-pipe FCU, 3-speed fan; Heat/Cool/Ventilation; up to 8 plans × 16 schedules |
| Outputs / Control | On/off motorized valve outputs + 3-speed fan; relay 4 A resistive / 3 A inductive; 1 × NTC input, 1 × dry-contact input |
| Temperature | –20 °C to +60 °C, accuracy ±0.5 °C (0–60 °C), resolution 0.1 °C |
| Humidity | 0–100 % RH, accuracy ±2 % (typ.), resolution 0.1 % RH |
| Display | 2.7" black & white E-Ink |
| Configuration | NFC via Mobile App, Downlink |
| Power | Mains 100–240 VAC, 50–60 Hz, < 2 W |
| Enclosure | PC+ABS (UL94 V0), IP20 |
| Dimensions | 86 × 86 × 42 mm |
| Mounting | 86 mm square or 60 mm round wall box |
| Certifications | CE, FCC |
Documentation
Safety information
- Read the manufacturer's user guide supplied with the product before installation and keep it.
- Use the product only for its intended use and within the operating conditions stated by the manufacturer. Do not use a visibly damaged product.
- Installation and connection may be carried out only by a person qualified in electrical installation, with the circuit de-energised. Risk of electric shock.
- Do not exceed the rated voltage and current stated by the manufacturer.
| Manufacturing company | XIAMEN MILESIGHT IOT CO.,LTD. |
|---|---|
| Address | 401, Building No.37, Xixishanwei Road, Software Park Phase III, Torch Development Zone for High Technology Industries, Xiamen, China |
| [email protected] | |
| Manufacturer's representative in the EU | HARDWARIO a.s. |
| Address of representative in the EU | U Jezu 525/4, 460 01 Liberec, Czech Republic |
| EU representative email | [email protected] |
