EURRAK Fiberglass Antenna 3dBi / 860-930 MHz (N-Type to RP-SMA)
RAK Fiberglass Antenna 3dBi / 860-930 MHz (N-Type to RP-SMA)
3 dBi omnidirectional fiberglass LoRaWAN® antenna for the 860–930 MHz band. IP67, 50 Ω, N-Type male, supplied with an N-Type→RP-SMA pigtail. More
Manufacturer: RAK
Product code: 99.26.3576.3183
Buying in volume? Write to [email protected] for an individual offer.
Free shipping from 125 EUR in the Czech Republic, 150 EUR to Slovakia and 250 EUR to all other countries we ship to (order value incl. VAT). All rates: Shipping and payment.
EU companies outside the Czech Republic with a valid VAT ID buy without VAT (reverse charge).
41,90 EUR
incl. VAT
3 dBi omnidirectional fiberglass LoRaWAN® antenna for the 860–930 MHz band. IP67, 50 Ω, N-Type male, supplied with an N-Type→RP-SMA pigtail. More
Manufacturer: RAK
Product code: 99.26.3576.3183
The RAK 3 dBi Fiberglass Antenna (860–930 MHz) is a compact outdoor, omnidirectional LoRaWAN® antenna in a rugged IP67 fiberglass radome. Its wide 860–930 MHz range covers the EU868, US915 and neighbouring sub-GHz LoRaWAN bands.
This version is supplied with an N-Type → RP-SMA pigtail cable (indoor use) for gateways and development boards with an RP-SMA port.
Parameters
| Frequency | 860–930 MHz |
| Gain | 3 dBi (2.6–3.1 dBi) |
| VSWR | ≤ 2.5 |
| Impedance | 50 Ω |
| Polarization | Vertical, 360° omnidirectional |
| Connector | N-Type male |
| Length | 360 mm (±10 mm) |
| Diameter | 25 mm |
| Radome | Fiberglass |
| Operating temperature | −20 °C to +65 °C |
| Ingress protection | IP67 |
Documentation
Safety information
- Read the manufacturer's user guide supplied with the product before installation and keep it.
- Use the product only for its intended use and within the operating conditions stated by the manufacturer. Do not use a visibly damaged product.
- Mount outdoor antennas so that they cannot touch power lines, and protect the installation against lightning according to local regulations.
- Keep a distance of at least 20 cm between a transmitting antenna and people.
- Outdoors, fix the product securely to a mast or structure strong enough for the wind load, and protect the installation against lightning according to local regulations.
