RAK Fiberglass Antenna 8 dBi / 858–878 MHz (N-Type to RP-SMA)
RAK Fiberglass Antenna 8 dBi / 858–878 MHz (N-Type to RP-SMA)
Buying in volume? Write to [email protected] for an individual offer.
Free shipping from 125 EUR in the Czech Republic, 150 EUR to Slovakia and 250 EUR to all other countries we ship to (order value incl. VAT). All rates: Shipping and payment.
EU companies outside the Czech Republic with a valid VAT ID buy without VAT (reverse charge).
The RAK 8 dBi fiberglass antenna is an outdoor antenna for LoRaWAN®, a long-range, low-power radio network. It radiates in all horizontal directions in the 858–878 MHz range. Its 8 dBi gain extends the range of LoRaWAN gateways and base stations in the EU868 band. The fiberglass radome is rated IP67.
- Gain: 8 dBi (±1 dBi), omnidirectional, vertical polarization.
- Size and mounting: 1 300 mm long, 25 mm in diameter. Wall and pole brackets are included.
- Connector: N-Type male. This version is supplied with an N-Type to RP-SMA pigtail cable (indoor use) for gateways and development boards with an RP-SMA port.
Parameters
| Frequency | 858–878 MHz |
| Gain | 8 dBi (±1 dBi) |
| VSWR | ≤ 1.5 |
| Impedance | 50 Ω |
| Polarization | Vertical, 360° omnidirectional |
| Connector | N-Type male |
| Length | 1300 mm (±25 mm) |
| Diameter | 25 mm |
| Radome | Fiberglass (white) |
| Operating temperature | −30 °C to +65 °C |
| Ingress protection | IP67 |
| Mounting | Wall/pole brackets included |
Documentation
Safety information
- Read the manufacturer's user guide supplied with the product before installation and keep it.
- Use the product only for its intended use and within the operating conditions stated by the manufacturer. Do not use a visibly damaged product.
- Mount outdoor antennas so that they cannot touch power lines, and protect the installation against lightning according to local regulations.
- Keep a distance of at least 20 cm between a transmitting antenna and people.
- Outdoors, fix the product securely to a mast or structure strong enough for the wind load, and protect the installation against lightning according to local regulations.
| Manufacturing company | Shenzhen RAKwireless Technology Co., Ltd. |
|---|---|
| Address | Room 506, Building B, New Compark, Pingshan First Road, Taoyuan Street, Nanshan District, Shenzhen, China |
| [email protected] | |
| Responsible person in the EU | HARDWARIO a.s. |
| Address of the responsible person in the EU | U Jezu 525/4, 460 01 Liberec, Czech Republic |
| E-mail of the responsible person in the EU | [email protected] |
